Ford Motor Reference # D7TZ-3504-E, D7TZ-3504-G, D9TZ-3504-B
Product Specs
Input Shaft Diameter (in) 0.72
Input Shaft Diameter (mm) 18.28
Input Shaft Spline Count 35
Installation Kit Included Yes
Manual Or Power Power
New Or Remanufactured New
Number Of Mounting Holes 3
Output Shaft Diameter (in) 1.31
Output Shaft Diameter (mm) 33.27
Output Shaft Spline Count 32
Power Steering Inlet Size 1/2-20
Power Steering Outlet Size 5/8-18
Pressure Port Thread Size 1/2-20
Return Port Thread Size 5/8-18
Turns Lock to Lock 4.0625
Warranty: 3 years, or 36,000 miles
Also recommend to replace your pump and hoses also.
|
